AIR 9.8 LTD Edition

£3,799.99 RRP £3,999.99
  • AIR 9.8 Limited Edition Aero Road Bike Carbon
Overview

The AIR is the most decorated machine in the Boardman range, with multiple Olympic victories on its palmares. With tube profiles shaped through extensive CFD and wind tunnel research, the AIR frame is designed for maximum speed.

A fast frame also deserves a fast set of wheels, and the 1610g Boardman Air Elite 7 2017 wheelset is just that. A 50mm deep rear rim is matched with a 38mm front to provide a winning combination both aerodynamic efficiency and controlled handling. The latest iteration of Shimano's Dura Ace Di2 provides flawless shifting even when you're stomping on the pedals, and internal cable routing means not a single Watt is lost.

With a strictly limited edition paint scheme set off with Vittoria Corsa tanwall tyres, not only will you be riding fast but you'll look amazing too.

Technical Specification
  • Frame: Boardman AIR, C10 Carbon
  • Fork: Boardman T9, Carbon, Carbon Tapered Steerer
  • Headset: FSA, No.42
  • Bottom Bracket: FSA BB-PF30
  • Cranks: Shimano Dura-Ace 9100
  • Chainrings: 52-36
  • Front Derailleur: Shimano Dura-Ace 9150
  • Rear Derailleur: Shimano Dura-Ace 9150
  • Shifter: Shimano Dura-Ace 9100, 11-25
  • Front Brake: TRP Integrated (TKB131)
  • Rear Brake: TRP (T714R)
  • Cassette: Shimano Ultegra 6800
  • Chain: KMC X11
  • Saddle: Prologo Zero 2
  • Seat Post: Boardman Elite AIR Carbon
  • Stem: Boardman Elite Carbon - 6° rise
  • Handlebar: Boardman Elite Alloy
  • Handlebar Tape: Boardman Soft-grip
  • Pedals: Pedals not included
  • Weight: 7.9 kg based on a medium bike
  • Wheelset: Boardman Air Elite Seven 2017
  • Tyre: Vittoria Open Corsa G+ (25C)
  • i C10 Carbon Frame

    Boardman's C10 Carbon uses ultra high modulus fibres in key areas of the frame, boosting stiffness whilst reducing overall frame weight

    Boardman's C10 Carbon uses a mixture of Toray T1000 and T800 or equivalent fibres. These high modulus fibres have outstanding stiffness to weight ratios, meaning that we can use less material to produce the same level of stiffness compared to lower grade fibres. This in turn means we can shape tubes more dramatically to tune the performance of the frame to suit the type of riding it is designed for. In the AIR range, the use of C10 Carbon facilitates a highly aerodynamic down tube and seat tube, comfort enhancing seat stays, and incredibly stiff chain stays for outstanding power transfer.

  • i Hidden Rear Brake

    The rear brake is located below the BB to maximise clean airflow at the rear of the frame

    We've placed the rear brake underneath the bottom bracket to keep it out of the air flow and improve aerodynamic performance. Don't worry about brake rub or lack of power though, the direct mount TRP brake used on the AIR has a longer travel than a standard caliper, giving better clearance for wide rims.

  • i PF30 Bottom Bracket

    PF30 gives a wider bottom bracket shell allowing us to profile chain stays for excellent aerodynamics and keep the bottom bracket stiff to provide outstanding power transfer

    The PF30 bottom bracket comprises of bearings in a plastic housing pressed directly into the frame. This means that the bottom bracket shell can be wider compared to a threaded bottom bracket as the bearings sit inside the frame, not outside. We've taken full advantage of this additional width to provide a solid and stiff junction between the BB and the chain stays to ensure your power is going into the road as efficiently as possible.

  • i 4 Position Seatpost

    The saddle clamp can be moved between 4 different positions on the seat post, allowing you to adjust the effective seat tube angle from 73°-75° for road, TT or Triathlon use

    Bike fitting is a complicated science, trying to find the best balance between comfort, power output and aerodynamics. With the 4 position seat post on the AIR platform, you have a huge range of adjustment to get the perfect fit. Being able to adjust from a 73°-75° seat tube angle also means the bikes can be used for mutliple disciplines, ride on the road at the weekend, then slide your saddle forwards and fit some aero-bars for a mid-week time trial.

Sizes & Fit
Standard Range Size
Recommended Height
Recommended Inseam (inside leg to floor)
Conventional Seat Tube
TT Top Tube
ST Seat Tube
HT Head Tube
HA Head Angle
SA Seat Angle
SA Seat Range
CS Chain Stay
FO Fork Offset (Rake)
BB Bottom Bracket Drop
Wheelbase
S Stack
R Reach
Stack to Reach Ratio
Standard Range Handlebar Width
Standard Range Stem Length
Standard Range Crank Length
View Geometry
  • XS
    167 - 172cm
    76 - 79cm
    52cm
    525
    460
    110
    72°
    74.5°
    74-76°
    405
    45
    68
    971
    511
    383
    1.33
    400
    100
    170
  • SM
    172 - 177cm
    79 - 81cm
    54cm
    540
    480
    135
    72.5°
    74°
    73-75°
    405
    45
    68
    978
    537
    386
    1.39
    400
    100
    170
  • MD
    177 - 183cm
    81 - 84cm
    56cm
    555
    500
    150
    73°
    73.5°
    73-75°
    405
    45
    68
    984
    553
    391
    1.41
    420
    110
    172.5
  • LG
    183 - 189cm
    84 - 89cm
    58cm
    570
    520
    170
    73°
    73°
    73-75°
    405
    45
    68
    993
    572
    395
    1.45
    440
    120
    175
  • XL
    189 - 200cm
    89 - 94cm
    60cm
    585
    535
    185
    73°
    73°
    73-75°
    405
    45
    68
    1008
    586
    405
    1.45
    440
    130
    175
